TP-Link TL-WR840N - wireless router - 802.11b/g/n - desktop

General

Device Type

Wireless router - 4-port switch (integrated)

Enclosure Type

Desktop

Connectivity Technology

Wireless, wired

Data Link Protocol

Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Frequency Band

2.4 GHz

Data Transfer Rate

300 Mbps

Network / Transport Protocol

PPTP, L2TP, IPSec, PPPoE, DDNS

Routing Protocol

Static IP routing

Encryption Algorithm

128-bit WEP, 64-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK

Features

DMZ port, DoS attack prevention, MAC address filtering, VPN passthrough, parental control, IP address filtering, Wi-Fi Multimedia (WMM) support, virtual server support, Wi-Fi Protected Setup (WPS), DHCP server, bandwidth control, port triggering, Stateful Packet Inspection Firewall (SPIF), DHCP client, DHCP reservation

Compliant Standards

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, FCC, RoHS

Expansion / Connectivity

Interfaces

LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX - RJ-45

Power

Power Device

External power adapter

Software / System Requirements

OS Required

Apple MacOS, Linux, Microsoft Windows 2000/XP/Vista/7/8/8.1/10

Dimensions & Weight

Width

18.2 cm

Depth

12.8 cm

Height

3.5 cm

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 90% (non-condensing)
