Ethernet LAN features |
Ethernet LAN: |
Yes |
Ethernet LAN data rates: |
10,100 Mbit/s |
Full duplex: |
No |
. |
Wireless LAN features |
Dual-band: |
No |
. |
Ports & interfaces |
WAN connection: |
Ethernet (RJ-45) |
Ethernet LAN (RJ-45) ports: |
4 |
DC-in jack: |
Yes |
. |
Mobile networking |
Data network: |
Not supported |
. |
Networking |
Networking standards: |
IEEE 802.3,IEEE 802.3u,IEEE 802.3x |
. |
Protocols |
DHCP client: |
Yes |
DHCP server: |
Yes |
Supported network protocols: |
TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS |
DMZ support: |
Yes |
. |
Management features |
Web-based management: |
Yes |
Reset button: |
Yes |
Quality of Service (QoS) support: |
Yes |
Universal Plug and Play (UPnP): |
Yes |
|
Security |
MAC address filtering: |
Yes |
Firewall: |
Yes |
Security algorithms: |
HTTPS |
VPN support: |
PPTP/L2TP/IP Sec |
. |
Design |
Colour of product: |
Blue |
Rack mounting: |
No |
LED indicators: |
Yes |
. |
Power |
Power consumption (typical): |
1.56 W |
Power over Ethernet (PoE): |
No |
. |
Operational conditions |
Operating temperature (T-T): |
0 - 40 °C |
Storage temperature (T-T): |
-40 - 70 °C |
Operating relative humidity (H-H): |
10 - 90 % |
Storage relative humidity (H-H): |
5 - 90 % |
. |
Certificates |
Certification: |
CE, FCC, RoHS |
. |
Other features |
Dimensions (WxDxH): |
209 x 126 x 26 mm |
Connectivity technology: |
Wired |
|
